Explore the detailed process of chip mounting and soldering on an ESA (Electronically Scanned Array) antenna panel in this step-by-step tutorial.
This video demonstrates the precision required for attaching RF chips and other components to the antenna panel, from initial alignment to final soldering. Perfect for professionals and enthusiasts working in high-frequency electronics, this guide covers key techniques including adhesive application, alignment, soldering, and testing.
Watch to gain insights into the critical stages of building high-performance antennas for advanced communication systems.
