GK800 Antenna
Ku-band high-performance flat OTM satellite antenna
GK800 Antenna
Ku-band high-performance flat OTM satellite antenna

GK800 Antenna

Ku-band high-performance flat OTM satellite antenna

The flat panel antenna is a WG-type direct RF signal transmission method that is suitable for small SNG vehicles with low energy loss and high power service.


Flat-panel antennas linked to motors can be installed easily and quickly on vehicles or railways to quickly and powerfully resolve the communication required by transportation.

Available for SNG vehicles

while on the move to the WG array antenna

The GK800 antenna is a direct transmission type OTM antenna that uses a compact high-power amplifier for high-performance image transmission.


Excellent communication network

connection for large amounts of on-the-go transmission

With the development of 5G communication networks, customers want to provide communication networks anytime, anywhere. It boasts an excellent communication network connection that can transmit 10Mbps in large quantities on the go through OTM function.


Hybrid communication

network connected to 5G backhaul

It can solve the emergency communication network of mobile relay vehicles for carrier press station recovery that can be used to recover 5G or LTE communication networks in case of disaster or war.

The flat panel antenna is a WG-type direct RF signal transmission method that is suitable for small SNG vehicles with low energy loss and high power service.


Flat-panel antennas linked to motors can be installed easily and quickly on vehicles or railways to quickly and powerfully resolve the communication required by transportation.

Available for SNG vehicles
while on the move to the WG array antenna


The GK800 antenna is a direct transmission type OTM antenna that uses a compact high-power amplifier for high-performance image transmission.

Excellent communication network

connection for large amounts of on-the-go transmission


With the development of 5G communication networks, customers want to provide communication networks anytime, anywhere. It boasts an excellent communication network connection that can transmit 10Mbps in large quantities on the go through OTM function.

Hybrid communication

network connected to 5G backhaul


It can solve the emergency communication network of mobile relay vehicles for carrier press station recovery that can be used to recover 5G or LTE communication networks in case of disaster or war.

Basic information

•  Model : GK800

•  Frequency Range : Standard Ku Band

•  Operation Range : TX: 14.0 ~ 14.50GHz

                                     RX: 12.25 ~ 12.75GHz

Basic performance

•  Gain : Tx  ≥ 37dBi, Rx  ≥36.5 dBi

•  G/T : ≥12.7 dB/K(10º Elevation 80ºK Clean Sky)

•  The first side lobe : 16dB

Scanning information

•  Scanning Range : Azimuth : 0° ~ 360° , Elevation 0° ~ 90°

•  Polarization : Linear H/V Pol

•  Cross Polarization : ≤30dB

•  Tracking : signal tracking

Operating performance

•  Initial dynamic satellite acquisition :  ≤3 min

•  Speed : highway : 150km/h, train : 300km/h

•  Product Size : Flat Array Φ1350mm×350mm, 65Kg

•  Operation Temperature : -40℃ ~ +55℃

RELATED RESOURCES

RELATED

PRODUCTS


VIDEO

KONET Mpack2

KONET Mpack2


Related Solutions

Basic information

Basic performance

•  Model : GK800

•  Frequency Range : Standard Ku Band

•  Operation Range : TX: 14.0 ~ 14.50GHz

                                     RX: 12.25 ~ 12.75GHz

•  Gain : Tx ≥ 37dBi, Rx ≥ 36.5 dBi

•  G/T : ≥12.7 dB/K (10º Elevation 80ºK Clean Sky)

•  The first side lobe : 16dB



Scanning information

Operating performance

•  Scanning Range : Azimuth : 0° ~ 360° , Elevation 0° ~ 90°

•  Polarization : Linear H/V Pol

•  Cross Polarization : ≤30dB

•  Tracking : signal tracking


•  Initial dynamic satellite acquisition : ≤3 min

•  Speed : highway : 150km/h, train : 300km/h

•  Product Size : ≤Flat Array Φ1350mm×350mm, 65Kg

•  Operation Temperature : -40℃ ~ +55℃
